[產品] Raspberry Pi PoE HAT (Power over Ethernet) 擴充板

2018-08-27 13:02:51 service

Raspberry-Pi-PoE-HAT-4in1

※改版中,暫時缺貨!

The Raspberry Pi PoE HAT powers a Raspberry Pi 3 Model B+ via an Ethernet cable. Power-sourcing equipment is required on the Ethernet network.

《特色》

The Raspberry Pi Power over Ethernet HAT is a small accessory for the Raspberry Pi computer. It can only be used with the Raspberry Pi 3 Model B+ (launched March 2018). The PoE HAT allows you to power your Raspberry Pi using Power over Ethernet–enabled networks; for this product to be used, the network it is connected to needs to have power-sourcing equipment installed.

Supplied with this product

  • Raspberry Pi PoE HAT
  • Mechanical spacers

Other hardware needed

Connecting your PoE HAT to the Raspberry Pi

  • Before installing the PoE HAT, you must attach the supplied spacers in the four corners of the board
  • Then connect the Raspberry Pi PoE HAT to the two 0.1” headers (40 + 4) that are fitted on the Raspberry Pi
  • Once the PoE HAT board is connected, you can power the Raspberry Pi through its RJ45 network connector

Disconnecting your PoE HAT

  • Take care when separating the HAT from the Pi
  • Pull evenly so that it detaches from all the pins at the same rate; do not pull one end of the connector off before the other

Additional information

No modification to the main Raspberry Pi board is needed for this product to work. Please ensure that your Raspberry Pi’s software is up to date for all functionality to be available. The PoE HAT is fitted with a small fan that is controlled by the Raspberry Pi via I2C. The fan will turn on and off automatically depending on the temperature of the main processor on the Raspberry Pi.

《規格》

The Raspberry Pi PoE HAT is an add-on board for the Raspberry Pi 3 Model B+. It allows the Raspberry Pi to be powered via a power-enabled Ethernet network.

  • 802.3af PoE
  • Fully isolated switched-mode power supply
  • 37–57V DC, Class 2 device
  • 5V/2.5A DC output
  • 25mm x 25mm brushless fan for processor cooling
  • Fan control

《下載》

《安全提醒》

  • Shall only be powered using 802.3af-compliant power sourcing equipment; any external power supply used with the Raspberry Pi shall comply with relevant regulations and standards applicable in the country of intended use
  • Should be operated in a well-ventilated environment, and should not be covered
  • Should be placed on a stable, flat, non-conductive surface while in use, and should not be contacted by conductive items

Instructions for safe use

To avoid malfunction or damage to your Raspberry Pi product, please observe the following advice:

  • Do not block or obstruct the fan
  • Do not insert anything into the fan at any time
  • Do not expose the product to water or moisture, and do not place it on a conductive surface whilst it is in operation
  • Do not expose it to heat from any source; the product is designed for reliable operation at normal room temperatures
  • Take care whilst handling to avoid mechanical or electrical damage to the printed circuit board and connectors
  • Avoid handling the Raspberry Pi while it is connected to a power outlet; only handle by the edges to minimize the risk of electrostatic discharge damage
  • All other peripherals used with the Raspberry Pi should comply with relevant standards for the country of use and be marked accordingly to ensure that safety and performance requirements are met; these peripherals include, but are not limited to, keyboards, monitors, and mice used in conjunction with the Raspberry Pi

* 注意:本商品不包含 Raspberry Pi 3 Model B+。

$ 840



※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: A+B+BQ24160CAT24C32HATLC709203FPi 2Pi 3pi supplyPiJuicePiJuice hatPIS-0212poe hatraspberry pishieldzerozero w擴充板擴展板樹莓派行動電源電源Raspberry-Pi-PoE-HAT-ss Read more...

[產品] PiJuice HAT - A Portable Power Platform For Every Raspberry Pi 樹莓派電源擴充板

2018-08-27 12:34:47 service

PiJuice-HAT-4in1



As one of the smallest systems around there are so many amazing things you could do with the Raspberry Pi if it was self-powered and portable. Introducing PiJuice! A fully uninterruptible power supply that will always keep your Raspberry Pi powered.

Our revolutionary PiAnywhere technology contained in every PiJuice HAT – is the best way to take your Pi off the grid! The real time clock (RTC) on board will let your Pi know what time it is even with no power input or internet connection. Alongside this is an integrated microcontroller (MCU) chip which will manage soft shut down functionality and a true low power deep sleep state and intelligent startup.

You will be able to always keep track of the charge levels and other info with the two built-in tri-coloured RGB LEDs, trigger events and scripts with the three programmable buttons and since the PiJuice will use up to just five of your GPIO pins (just power and I2C), the rest are free to diversify your project. The stacking header allows you to continue to use your existing HATs and add-ons with PiJuice.

《特色》

  • Onboard 1820 mAh off the shelf Lipo / LiIon battery for ~4 to 6 hours in constant use! (with support for larger Lipo Battery of 5000 or 10,000 mAH+ to last up to 24 hrs +)
  • A Full Uninterrupted / Uninterruptable Power Supply solution.
  • Designed for the Raspberry Pi A+, B+, 2B, 3B and 3B+ but also compatible with Raspberry Pi Zero v1.3 and Raspberry Pi Zero Wireless.
  • Integrated Real Time Clock
  • Onboard intelligent on/off switch
  • Low power deep-sleep state with wake on interrupt/calendar event
  • Programmable multi-colored RGB led (x2) and buttons (x3) with super simple user-configurable options
  • Hardware watchdog timer to keep your Raspberry Pi on and working in mission-critical remote applications
  • Our revolutionary PiAnywhere technology ? the best way to take your Pi off the grid!
  • Full power management API available to Raspberry Pi OS with auto shutdown capability when running low on batteries
  • Raspberry Pi HAT compatible layout, with onboard EEPROM for easy plug and play operation
  • Low profile design to fit inside lots of existing Raspberry Pi cases!
  • Enhanced graphical user interface (GUI) available for easy install (via APT)
  • Customisable scripts for enhanced flexibility and full report of battery status
  • All GPIOs available via stackable header for ease of expandability and connectivity
  • Charge via on-board micro USB or via the Raspberry Pi micro USB (or from onboard pin headers)
  • Batteries can be charged from different type of sources and voltages
  • Replace the battery without downtime. Compatible with any single cell LiPo or LiIon battery
  • Fully CE and FCC tested design. Battery safety tested also.



《規格》

  • The EEPROM can be disabled and its I2C address changed for increased compatibility with other boards
  • BP7X battery – original battery from Motorola Droid 2 (A955) – 1820mAh battery
  • Microcontroller is an ST Micro STM32F030CCT6 ARM Cortex-M0, 48MHz, F64KB, R8KB, I2C, SPI, USART, 2.4-3.6V
  • Charge IC – BQ24160RGET Charger IC Lithium-Ion/Polymer, 2.5A, 4.2-10V
  • Fuel gauge IC – LC709203FQH-01TWG Battery Fuel Gauge, 1-Cell Li-ion, 2.8%
  • EEPROM – CAT24C32WI-GT3 EEPROM, I2C, 32KBIT, 400KHZ, 1V7-5V5
  • Optional spring pin – Mil-Max 0929-7-15-20-77-14-11-0
  • Compatible with any 4 pin battery on board that can be used with 00-9155-004-742-006 battery contacts from AVX including the BP7X, BP6X, and any compatible batteries including the 1600mAh and 2300mAh
  • ones from CameronSino (CS-MOA853SL and CS-MOA855XL)
  • There is an on board 4 pin screw terminal block for larger off board batteries. Any single cell LiPo / LiIon is compatible. However, you use your own sourced battery at your own risk. We HIGHLY RECOMMEND using
  • a battery with an internal protection circuit and a NTC (temp sensor)
  • Optional header for offboard button – connected to same output as SW1
  • 6 pin breakout header – with two GPIO from the ARM Cortex-M0, Vsys, 5v0, 3v3, GND connections
  • Header for optional off board solar panel / wind turbine etc.
  • Optional RF Shield attachment – Harwin S02-20150300 (can also double as an inexpensive heatsink)
  • Input voltage range – 4.2V 10V
  • Output voltage – 3.3V and 5V
  • Output amperage – maximum current at 5V gpio is 2.5A and at VSYS output 2.1A, but also this depends heavily on battery capacity. For BP7X have measured around 1.1A at 5V GPIO and around 1.6A at VSYS
  • output. Obviously, this also depends heavily on the current draw demanded by the Raspberry Pi/device itself. To achieve a maximum of 2.5A it will need battery over 3500mAh.
  • Boxed weight – 96g
  • Boxed dimensions – 12.2 x 10.8 x 3.5 cm
  • Unboxed weight – 57g
  • Unboxed dimensions – 6.5 x 5.6 x 2 cm

PiJuice HAT box contains

  • 1 x PiJuice HAT
  • 1 x Battery and battery surround
  • 1 x PiJuice guide
  • 4 x Mounting posts attached to PiJuice
  • 8 x Mounting screws (4 are already assembled to the board)
  • 1 x Pogo pin
  • 3 x Stickers



《下載》

《應用》

* 注意:本商品不包含 Raspberry Pi 主板。

$ 2450



※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: "Raspberry Pi 3 B+"A+ARMB+BP6XBP7XBQ24160RGETCameronSinoCortex-M0CS-MOA853SLCS-MOA855XLEEPROMGPIOI2CLiIonLiPoLiPo / LiIonPi 2Pi 3pi 3 B+pi 3 Model B+PiJuice hatReal Time ClockRTCSPISTM32F030CCT6switchusartzero wPiJuice-HAT-ss Read more...

[產品] Raspberry Pi 3 Model B+(現貨)

2018-03-21 09:52:11 service

SONY DSC

與 Pi 3 最大的改變是網路效能增加了,CPU 時脈也從 1.2GHz 微增加到 1.4GHz。

《新的改變》
1. 使用 BCM2837B0 晶片(原本為 BCM2837) 64-bit quad-core ARM Cortex-A53,單核心時脈可達 1.4GHz。
2. 使用 Cypress CYW43455 雙頻晶片(原本為 CYW43438),支援 2.4GHz 和 5GHz 雙頻,並支援 Bluetooth 4.2。
3. 使用 LAN7515(原本為 LAN951x),支援 Gigabit Ethernet over USB 2.0。
4. 支援 Power-over-Ethernet,由四根新增的 Pin 做控制,但要搭配官方擴充板。
5. 更好的溫度管理,在不同溫度下可自動調整 CPU 速度。

《規格》

SoC: Broadcom BCM2387B0 chipset
CPU: 1.4GHz Quad-Core ARM Cortex-A53 (64Bit)
GPU: Dual Core VideoCore IV® Multimedia Co-Processor. Provides Open GL ES 2.0; hardware-accelerated OpenVG; and 1080p30 H.264 high-profile decode
記憶體: 1GB LPDDR2(和 GPU 共享)
視訊輸出: Composite RCA; HDMI
音訊輸出: 3.5 mm jack; HDMI(1.3 & 1.4)
儲存: microSD
USB: USB 2.0 x 4
Ethernet: Gigabit Ethernet over USB 2.0 (maximum throughput 300Mbps)
Wireless: 2.4GHz and 5GHz IEEE 802.11.b/g/n/ac wireless LAN
Bluetooth: Bluetooth 4.2;Bluetooth Low Energy(BLE)
GPIO: 40-pin 2.54 mm (100 mil) expansion header: 2×20 strip
工作電流: 459mA(2.295W) when idle/1.13A(5.661W) maximum under stress
尺寸: 85mm x 56mm x 17mm
重量: 50g

《下載》
* Raspberry Pi 3 Model B+ Spec
* Raspberry Pi 3 Model B+ mechanical drawing

《新聞》
* [新聞] Raspberry Pi 3B+出來了!

《教學》
* [常見問與答] 如何更新Raspbian?

《相關》
* [產品] Official Pi 3 Model B/B+ 紅白雙色外殼
* [產品] HDMI 轉 VGA 轉換器(帶音訊)
* [產品] 5V/2.5A 電源轉換器(20AWG)–Raspberry Pi 3 以下版本皆適用

注意:目前還不支援 Windows IoTAndroid Things

$ 1470

※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: "Raspberry Pi 3 B+""Raspberry Pi 3B+ - Model B Plus""樹莓派 3B +"1.4GHz3x Faster3倍速5.1V/2.5A5GHz5V/2.5A64BitAndroid ThingsARMBCM2837BCM2837B0BLEBluetooth 4.2chipCortex-A53CYW43455Dual BandEthernetGigabitLAN7515New Productnew versionPi 3Pi 3BPi 3B+ PlusPi3B+Pi3B+PlusPoEPower-over-EthernetproductPXEraspberry piRaspberry Pi 3Raspberry Pi 3 B PlusRaspberry Pi 3 BplusRaspberry Pi 3 Model BRaspberry Pi 3BRaspberry Pi 3B PlusRaspberry Pi 3B+ (Model 3B+)VideoCoreWindows IoT乙太網路台灣樹莓派官方新版本新產品晶片樹莓派樹莓派 3樹莓派3B+. 樹莓派3B溫度管理無線網路現貨產品芯片藍牙雙頻電源電源供應器Raspberry-Pi-3B-Plus-ss Read more...

[產品] NanoSound DAC Pro for Raspberry Pi 擴充板

2017-10-25 23:04:34 service

2017 年 8 月 NanoSound 在 Kickstarter 完成募資。NanoSound DAC 是Raspberry Pi 的擴充板,內建 HIFI DAC、LDO 穩壓器(Voltage Regulator)、OLED 顯示器、電源開關、控制按鈕和紅外線遙控。

NanoSound 是一個專為音響玩家所推出的樹莓派擴充板。使用 24bit / 112dB Hi-Fi Audio DAC,大大提高了樹莓派的音質。

nanosound-dac-pro-0

《規格》

  • Texas Instruments PCM5122 DAC
    - 192kHz Sampling Rate / 24bit Resolution Burr-Brown DAC for best sound quality
    - Hardware volume control for best quality using “alsamixer”
  • Texas Instruments TPS7A4700 Ultra Low Noise Voltage Regulator
  • Switchable Power Option
    - Power from a single microUSB port or independently
  • Raspberry Pi Power switch
    - Turn on and Gracefully shut down Raspberry Pi System
  • 6 GPIO buttons for Media Control
  • Infrared Receiver and Remote Control
    - LIRC compatible
  • 1.3″ OLED display with multi-language support.
    - Resolution: 128 x 96
  • Pure Copper Gold Plated RCA Connector

* 注意:本商品不包含 Raspberry Pi 3、SD card、NanoSound AMP^2!

《新聞》
* NanoSound技術總監 Andrew 來訪
* 與 NanoSound 技術總監小訪:提供具小螢幕、可獨立操作的樹莓派聽音樂神器

nanosound-dac-pro-3
NanoSound DAC Pro(含 OLED 顯示和紅外線遙控)
$2280

3d-printed-case-black
NanoSound 3D Printed Case(黑)
$980

nanosound-dac-pro-1
NanoSound 3D Printed Case(白)
$980

nanosound-dac-pro-2
NanoSound DAC Pro + 3D Printed Case(白)
$3100


NanoSound DAC Pro + 3D Printed Case(黑)
$3100

※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: 3D3D PrintedalsamixerAmpAmp^2casedacDDCdemo hatHATI2SKickstartermusicnanomesherNanosoundNanoSound DAC PropackagePCM5122playproductTItps7a4700visitVolumio保護殼外殼套件套餐播放擴充板擴大器擴大機數位轉光纖/同軸數位類比轉換產品組合預購nanosound-dac-pro-ss Read more...

[產品] ReSpeaker 四麥克風陣列擴充板(ReSpeaker 4-Mic Array for Raspberry Pi)

2017-09-26 14:34:29 service

respeaker-4-mic-array-s

《特色》
* 適合語音產品,能讓您輕易的接上 Google AssistantAmazon AlexaJasperIBM Watson 等語音服務。
* 使用 AC108 開發,內建四通道 ADC,具有 I2S/TDM 輸出轉換,能擷取高清晰度的語音輸入。
* 包含四個麥克風,可進行語音活性檢測(Voice activity detection,VAD)和方向定位(Direction of Arrival, DOA)。
* 三公尺遠收音。

* 注意:和 ReSpeaker雙麥克風擴充板(2-Mics Pi HAT) 不同,該擴充板沒有耳機插孔提供音訊輸出。

respeaker-4-mic-array-4in1-s

《規格》
* Raspberry Pi Zero / Zero W / B+ / Pi 2 / Pi 3 適用
* 4 analog microphones
* 2 個 Grove 介面: 支援 GPIO 及 I2C
* 12 APA102 可程式化 RGB LEDs,使用 SPI 介面
* 可遠至 3 公尺外收音
* 尺寸: 65mm x 65mm x 9mm
* 重量:G.W 20g

* 注意:本商品不包含 Raspberry Pi !

《下載》
* ReSpeaker 4-Mic Array for Raspberry Pi v1.0.pdf
* AC108_Datasheet_V1.1

《教學》
* [Wiki] ReSpeaker 4-Mic Array for Raspberry Pi
* 改造 ReSpeaker 2-MIC HAT 教學投影片

《HackMD》
* 改造 ReSpeaker 2-MIC HAT

《範例程式》
* https://github.com/raspberrypi-tw/hack-respeaker

$800


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: 4-Mic4-Mic ArrayAIYAlexaAmazonAmazon AlexaAPA102Direction of ArrivalDOAgithubGoogleGoogle AssistantGrovehackmdHATI2SIBMIBM WatsonJaspermicrophoneOpen HardwareOpen Source HardwarePi 3programableraspberry pirespeakerrespeaker 4-mic arrayRGBRGB LEDseeedSeeedStudioServiceSpeech to TextSTTTDMText to SpeechTTSVADVoiceVoice Activity DetectionWatson助理可程式化四麥克風开源开源硬件控制擴充板教學文字語音轉換方向方向定位方向檢測服務矽递矽递科技矽遞矽遞科技語音語音助理語音文字轉換語音服務語音活性檢測開源開源硬件開源硬體陣列麥克風麥克風陣列respeaker-4-mic-array-ss Read more...

[產品] Raspberry Pi 樹莓派鋰電池 電源擴充板 行動電源 雙USB輸出

2017-08-30 10:55:55 service

RPi-PowerPack-v1.2-4in1

專為樹莓派設計的鋰電池行動電源,雙USB輸出,重量只有80g,也可用於其他USB供電等設備。

《特色》

  • 適用於B+以後版本樹莓派,Raspberry Pi A+, B+, 2B, 3B and 3B+
  • CHG LED:
    亮:充電器進行恆流充電。
    滅:充電器進行浮充,直到鋰電充滿。
  • ON LED作用:
    亮:USB 供電中。
    滅:USB 停止供電。

《規格》

  • 容量:3800mAH
  • 最大放電電流:1.4A
  • 空載輸出電壓:5.1V ±0.1V
  • 標準充電電流/電壓:1.0A@5.0V
  • 鋰電池充滿截至電壓:4.18V – 4.2V

* 注意:本商品不包含 Raspberry Pi 主板。

$ 350



※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: model bPi 3pi 3 B+powerpower supply擴充板移動電源行動電源鋰電雙USB雙輸出電源???????? Read more...

[產品] Adafruit 16-Channel PWM / Servo HAT for Raspberry Pi(未銲) 伺服馬達擴充板

2017-08-29 18:52:32 service

Adafruit-16-Channel-PWM-Servo-HAT-for-Raspberry-Pi-Mini-Kit



The Raspberry Pi is a wonderful little computer, but one thing it isn’t very good at is controlling DC Servo Motors – these motors need very specific and repetitive timing pulses to set the position. Instead of asking the Pi Linux kernel to send these signals, pop on this handy HAT! It adds the capability to control 16 Servos with perfect timing. It can also do PWM up to 1.6 KHz with 12 bit precision, all completely free-running.

《規格》
- Raspberry Pi Model A+, B+, or Pi 2 適用
- Servo HAT x1
- 2-pin terminal block x1
- 3×4 headers x4
- 2×20 socket header x1

* 注意:本產品不含Raspberry Pi及伺服馬達。

$ 700


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: A+adafruitB+Pi 2PWMraspberry piservo伺服馬達擴充板舵機Adafruit-DC-Stepper-Motor-HAT-for-Raspberry-Pi-Mini-Kit-ss Read more...

[產品] Adafruit DC & Stepper Motor HAT for Raspberry Pi - Mini Kit(未銲) 直流 & 伺服馬達擴充板

2017-08-29 18:19:38 service

Adafruit-DC-Stepper-Motor-HAT-for-Raspberry-Pi-Mini-Kit-4in1

Let your robotic dreams come true with the new DC+Stepper Motor HAT from Adafruit. This Raspberry Pi add-on is perfect for any motion project as it can drive up to 4 DC or 2 Stepper motors with full PWM speed control.

《規格》
- 65mm x 56mm x 13mm / 2.6″ x 2.2″ x 0.5″
- Raspberry Pi Model A+, B+, Pi 2, Pi 3, Pi 3 Model B+皆適用
- Servo HAT x1
- 2-pin terminal block x3
- 3-pin terminal block x2
- 2×20 socket header x1

* 注意:本產品不含Raspberry Pi及馬達。

《教學》
Adafruit DC and Stepper Motor HAT for Raspberry Pi
Simple Raspberry Pi Robot

《下載》
Datasheets, schematic, PCB files, and Fritzing available in the product tutorial

$ 900


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: A+adafruitB+DCl293dMotor HATPi 2Pi 3pi 3 B+PWMraspberry piStepperTB6612TB6612 MOSFET伺服擴充板直流馬達馬達擴充板Adafruit-DC-Stepper-Motor-HAT-for-Raspberry-Pi-Mini-Kit-ss Read more...

[產品] ReSpeaker雙麥克風擴充板(2-Mics Pi HAT)

2017-08-18 14:37:44 service

ReSpeaker-2-Mics-Pi-HAT-s

《特色》
ReSpeaker 2-Mics Pi HAT 是一個適用於語音應用的雙麥克風擴充板。該擴充板使用 WM8960 的低功耗立體聲編解碼器,兩側有兩個麥克風可收音,讓您可以很容易的串接 Amazon Alexa Voice Service 或是 Google Assistant 等語音服務。此外,擴充板上還有 3 個 APA102 RGB LED,1 個按鍵和 2 個 Grove 介面,讓您很容易擴充其他硬體與應用程式。板上的 3.5mm 音訊插孔或 JST 2.0 揚聲器輸出均可用於音訊輸出。

ReSpeaker-2-Mics-Pi-HAT-4in1

《規格》
* Raspberry Pi Zero / Zero W / B+ / Pi 2 / Pi 3 適用
* 雙麥克風
* 2 個 Grove 介面: 支援 GPIO 及 I2C
* 可程式化控制按鍵及 LED 燈(包括 1 按鍵和 3 LED 燈)
* 內鍵音訊編/解碼器
* 雙音訊輸出: 3.5mm 音訊插孔、JST2.0 揚聲器輸出
* 可遠至 3 公尺外收音
* 尺寸: 65mm x 30mm x 15mm
* 重量:G.W 34g N.W 12g

* 注意:本擴充板不包含 microSD卡 及 Pi Zero!

《使用教學》
* [Wiki]ReSpeaker 2-Mics Pi HAT
* 1.Get started with Google Assistant
* 2.How to use button to trigger Google Assistant
* 改造 ReSpeaker 2-MIC HAT 教學投影片

《HackMD》
* 改造 ReSpeaker 2-MIC HAT

《範例程式》
* https://github.com/raspberrypi-tw/hack-respeaker

《相關》
* [新聞] Raspberry Pi Zero 套餐特價中
* [產品] Raspberry Pi Zero v1.3 + Mini HDMI轉接頭 + OTG + 8G microSD + 5V電源 + 2×20排針
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi Camera(v2)
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi NoIR Camera(v2)

$680


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: 2-Mics2-Mics Pi HATAlexaAmazonAPA102dual-microphoneexpansion boardgithubGoogle AssistantGrovehackmdHATmicrophoneOpen HardwareOpen Source HardwarePi HATraspberry piRaspberry Pi 3respeakerrespeaker 2-mics Pi HATReSpeaker雙麥克風擴充板ReSpeaker雙麥克風擴充板(2-Mics Pi HAT)seeedSeeedStudioVoicevoice controlvoice inputvoice recognitionvoice servicewikiWM8960zero开源开源硬件按鍵揚聲器擴充板擴展板樹莓派矽递矽递科技矽遞矽遞科技語音控制語音服務語音輸入語音辨識開源開源硬件開源硬體雙麥克風雙麥克風擴充板麥克風ReSpeaker-2-Mics-Pi-HAT-ss Read more...

[產品] PiJack Ethernet HAT for Pi Zero

2017-04-10 18:01:59 service

PiJack-Ethernet-HAT-for-Pi-Zero-0

《規格》
* 10Mbps 乙太網路連線
* 雙 LED 燈顯示連線狀態
* HAT-standard-compliant EEPROM makes setup automatic, works straight away with Raspbian!
* 使用 Zero 的 GPIO 腳位,不佔用 USB 孔!
* 長 x 寬 x 高:65.5mm x 32.3mm x 23.0mm / 2.6″ x 1.3″ x 0.9″
* 重量:15.6g / 0.6oz

PiJack-Ethernet-HAT-for-Pi-Zero

* 注意:本擴充板不包含 Pi Zero 及網路線!

《使用教學》
* PiJack setup guide

《新聞》
* [新聞] Raspberry Pi Zero W

《相關》
* [新聞] Raspberry Pi Zero 套餐特價中
* [產品] Raspberry Pi Zero v1.3 + Mini HDMI轉接頭 + OTG + 8G microSD + 5V電源 + 2×20排針
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi Camera(v2)
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi NoIR Camera(v2)

$ 630

Tagged in: 10MbpsEthernetEthernet HATGPIOHATpi zeroPi Zero WPiJackraspberry pi zero wRJ45zerozero w乙太網路擴充板PiJack-Ethernet-HAT-for-Pi-Zero-0-ss Read more...

[產品] Raspberry Pi Zero W 基本套件

2017-03-14 11:57:04 service

Raspberry-Pi-Zero-W-Basic-Pack

《規格》
* Raspberry Pi Zero W x1
* Adafruit Pi Zero Enclosure x1
* 8GB SD Card x1

《新聞》
* [新聞] Raspberry Pi Zero W

《相關》
* [新聞] Raspberry Pi Zero 套餐特價中
* [產品] Raspberry Pi Zero v1.3 + Mini HDMI轉接頭 + OTG + 8G microSD + 5V電源 + 2×20排針
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi Camera(v2)
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi NoIR Camera(v2)

$ 1400


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: adafruitBCM43438BluetoothCYW43438packagePi Zero Wraspberry pi zero wWiFizero套餐Raspberry-Pi-Zero-W-Basic-Pack-ss Read more...

[產品] Raspberry Pi Zero W 進階套件

2017-03-14 11:54:42 service

Raspberry-Pi-Zero-W-Budget-Pack

《規格》
* Raspberry Pi Zero W x1
* Mini HDMI to HDMI Adapter x1
* USB OTG Cable x1
* 8GB SD Card x1
* Adafruit Pi Zero Enclosure x1
* 5V 2A Power Supply w/ Micro USB Cable x1
* 2×20 Male header strip x1

《新聞》
* [新聞] Raspberry Pi Zero W

《相關》
* [新聞] Raspberry Pi Zero 套餐特價中
* [產品] Raspberry Pi Zero v1.3 + Mini HDMI轉接頭 + OTG + 8G microSD + 5V電源 + 2×20排針
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi Camera(v2)
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi NoIR Camera(v2)

$ 1800


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: adafruitBCM43438BluetoothCYW43438packagePi Zero Wraspberry pi zero wWiFizero套餐Raspberry-Pi-Zero-W-Budget-Pack-ss Read more...

[產品] Red Bear IoT pHAT for Raspberry Pi - WiFi + BTLE

2017-03-01 14:01:53 service

red-bear-iot-phat-for-pi_wifi-and-ble

《特色》
* AMPAK AP6212A Wireless Module (Broadcom BCM43438 A1 chip inside)
* Single antenna for concurrent WiFi and Bluetooth operations
* 32 Kbit (4 KByte) EEPROM for DTOverlay configuration
* 40-pin connector
* FCC/CE certified
* 已預先焊接好 40-pin 母排座

Red-Bear-IoT-pHAT-for-Raspberry-Pi-WiFi-BTLE-1

《規格》
* 支援 WiFi (802.11bgn / 2.4GHz)。使用 SDIO v2.0,頻寬可達 20 MHz
* 支援 Bluetooth (4.1) 和 BLE。使用 UART,傳輸速度可達 4 Mbps
* 長 x 寬 x 高: 65.0mm x 30.0mm x 11.0mm / 2.6″ x 1.2″ x 0.4″
* 重量: 10.5g
* 注意:本擴充板不包含 Pi Zero!

《使用教學》
* RedBear IoT pHAT

《相關》
* [新聞] Raspberry Pi Zero 套餐特價中
* [產品] Raspberry Pi Zero v1.3 + Mini HDMI轉接頭 + OTG + 8G microSD + 5V電源 + 2×20排針
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi Camera(v2)
* [產品] Raspberry Pi Zero v1.3 + Raspberry Pi NoIR Camera(v2)

$ 680


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: 802.11802.11bgnBCM43438BLEBluetoothBluetooth Low EnergyBT 4.1BTLECYW43438HATIoTpHATpi zeroraspberry pi zeroRed BearRedBearWiFizero擴充板藍牙Red-Bear-IoT-pHAT-for-Raspberry-Pi-WiFi-BTLE-0-ss Read more...

[產品] Raspberry Pi Compute module 3 (CM3)

2017-01-20 13:28:11 service

Raspberry Pi Compute module 3

RPI-COMPUTE3-2in1

The Raspberry Pi Compute Module 3 (CM3) and Compute Module 3 Lite (CM3L) are DDR2-SODIMM-mechanically-compatible System on Modules (SoMs) containing processor, memory, eMMC Flash (CM3 only) and supporting power circuitry. These modules allow a designer to leverage the Raspberry Pi hardware and software stack in their own custom systems and form factors. In addition the modules have extra IO interfaces over and above what is available on the Raspberry Pi model A/B boards, providing more options for the designer.

《特色》

The Compute Module 3 contains the following components contained within a 200 pin SODIMM design:

  • Broadcom BCM2837 processor
  • 1Gbyte LPDDR2 RAM
  • 4Gbytes eMMC Flash
  • 35u hard gold plated IO Pins

單買CM3 $1470



Raspberry Pi Compute module 3 Lite

RPI-COMPUTE3-LT-2in1

《特色》

The Compute Module 3 Lite product is the same as the Compute Module 3 except the eMMC Flash is not fitted, and the SD/eMMC interface pins are available for the user to connect their own SD/eMMC device The Compute Module 3 Lite contains the following components contained within a 200 pin SODIMM design:

  • Broadcom BCM2837 processor
  • 1Gbyte LPDDR2 RAM
  • 35u hard gold plated IO Pins

(N.B. when operating with the IO Board, an SD card with a suitable image must be connected to the IO board for the system to work)
單買CM3 Lite $1260



Raspberry Pi 3 Compute Module I/O

Raspberry-Pi-3-compute-module-IO-2in1

《特色》

This is the main development kit IO board into which the Compute Module SODIMM board is connected. It also contains all of the necessary interface ports to allow an engineer to design and test their own prototype application.

The IO board contains the following interfaces:

  • Multiple GPIO interfaces on 2 60 way 0.1” Headers
  • 1 x Micro USB connector type B – USB Slave
  • 1 x USB connector type A – USB Host
  • 2 x CSI ports for camera boards
  • 2 x DSI ports for display boards
  • Full size HDMI port
  • Micro USB power connector
  • Micro SD connector

單買Compute Module I/O Board $5150



Raspberry Pi Compute Module 3 Development Kit

RPI-COMPUTE3-KIT-4in1

《特色》

The Raspberry Pi Compute Module 3 Development Kit contains the following components:

  • 1 x Raspberry Pi Compute Module 3
  • 1 x Raspberry Pi Compute Module 3 Lite
  • 1 x Raspberry Pi Compute Module IO Board
  • 1 x Raspberry Pi Compute Module IO Board Camera Display Adaptor
  • 1 x 5v 2.5A Power Supply
  • 1 x USB A to micro B cable
  • 4 x Jumper wires

《下載》

The schematics and board design files for the Compute Module IO board have been published by the Raspberry Pi Foundation and detail the interconnection between the SODIMM socket and the interfaces on the IO board. These can be found at: https://www.raspberrypi.org/documentation/hardware/computemodule/

購買全套CM3 Development Kit $8200


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: 123-2011123-2012123-2013BCM2837CM3cm3 litecompute modulecompute module 3Compute module 3 I/OCompute Module 3 LiteI/O boardPi 3raspberry piRaspberry Pi 3Raspberry Pi Compute module 3 I/O boardRPI-COMPUTE3-KIT-ss Read more...

[產品] Raspberry Pi Sense HAT 擴充板

2016-10-10 18:15:57 service

raspberry-pi-sense-hat

《特色》
內建多種感測器,包括陀螺儀(​Gyroscope)、加速度計(Accelerometer)、電子羅盤(Magnetometer)、氣壓計(Barometer)、溫度感測器(Temperature sensor)、相對濕度感測器(Relative humidity sensor)與 8×8 RGB LED 矩陣顯示, 可以在沒有螢幕的情況下顯示各種資訊。
適合 Pi 3/Pi 2/Model B+/Model A+ 使用。

《規格》

Gyroscope: ~245/500/2000 (dps)
Accelerometer: ~2/4/8/16 (g)
Magnetometer: ~4/8/12/16 (gauss)
Barometer: 260 – 1260 hPa (Accurate ~0.1 hPa)
Temperature sensor: 0-65°C (Accurate ~2°C)
Relative humidity sensor: 20-80% rH (Accurate ~4.5%); 15-40°C (Accurate ~0.5°C)
8×8 RGB LED matrix display
Small 5 button joystick
Dimensions: 65.1mm x 56.6mm x 13.9mm
Weight: 20.4g

《新聞》
* THE SENSE HAT: HEADGEAR FOR THE TERMINALLY CURIOUS
* SENSE HAT EMULATOR
* GETTING STARTED WITH THE SENSE HAT
* SENSE HAT ESSENTIALS

《範例程式》
* Python library

《應用》
* SENSE HAT MINECRAFT MAP
* SENSE HAT MARBLE MAZE

$ 1380



[產品] Raspberry Pi Sense HAT 擴充板專用外殼

sensor-hat

$ 320


※若無法使用Paypal購買,請到 這裡 填寫表單購買,造成您的不便敬請見諒。

Tagged in: accelerometerbarometergyroscopeHATmagnetometerofficialrelative humidity sensorRGB LED matrixsensetemperature sensor加速度計官方擴充板氣壓計溫度感測器相對濕度感測器陀螺儀電子羅盤 Read more...

[產品] Raspberry Pi 3 Model B (現貨)

2016-03-15 14:02:56 service

Raspberry-Pi-3-Model-B
《規格》

SoC: Broadcom BCM2837
CPU: 1.2 GHz 64-bit quad-core ARM Cortex-A53
GPU: Dual Core VideoCore IV® Multimedia Co-Processor; Open GL ES 2.0; hardware-accelerated OpenVG; 1080p60 H.264 high-profie decode
記憶體: 1GB LPDDR2(和 GPU 共享)
視訊輸出: Composite RCA; HDMI
音訊輸出: 3.5 mm jack; HDMI(1.3 & 1.4)
儲存: microSD
USB: USB 2.0 x 4
Ethernet: 10/100 RJ45
Wireless: 802.11n
Bluetooth: Bluetooth 4.1; Bluetooth Low Energy(BLE)
GPIO: 40-pin 2.54 mm (100 mil) expansion header: 2×20 strip
工作電流: 800 mA
尺寸: 85mm x 56mm x 17mm
重量: 42g

《下載》
* Raspberry Pi 3B v1.2 Schematics
* BCM43438(CYW43438)
* SMSC LAN9514-JZX USB and Ethernet controller

《新聞》
* [新聞] Raspberry Pi 3 Model B

《相關》
* [產品] Official Model B Pi 3 紅白雙色外殼
* [產品] HDMI 轉 VGA 轉換器(帶音訊)
* [產品] Raspberry Pi 3 Model B + 外殼 + 5V/2A電源組

$ 1600

Tagged in: 1.2 GHz64-bit802.11nBCM2837BCM43438BLEBluetooth 4.1Bluetooth Low EnergyCortex-A5CYW43438LAN9514productQuad-coreRaspberry Pi 3Raspberry Pi 3 Model BSMSC四核心產品 Read more...

[產品] Pimoroni Skywriter HAT - 3D 手勢感測擴充板

2016-02-15 15:38:31 service

Skywriter-HAT

《特色》
* 電子式近場(near-field) 3D/手勢(gesture)感應
* 5cm 感應距離
* 可取得完整的 3D 位置資訊
* 相容於 Raspberry Pi 3, Pi 2, B+ 和 A+
* 完整的 Python API

《規格》
* 尺寸:56 x 65 x 2mm (LxWxD)
* 重量:15g
* 注意:本外殼不包含 Raspberry Pi 與外殼

《專案》
* Gesture Based TV Remote Control

$ 980

Tagged in: 3DgestureHATnear-fieldpimoroniSkywriter手勢近場 Read more...

[產品] Raspberry Pi 2 Model B

2015-02-05 11:02:46 service

Raspberry-Pi-2-Model-B

《規格》

SoC: Broadcom BCM2836
CPU: 900 MHz;Quad-core ARM Cortex-A7
GPU: Dual Core VideoCore IV® Multimedia Co-Processor; Open GL ES 2.0; hardware-accelerated OpenVG; 1080p30 H.264 high-profie decode
記憶體: 1GB LPDDR2(和 GPU 共享)
視訊輸出: Composite RCA; HDMI
音訊輸出: 3.5 mm jack; HDMI(1.3 & 1.4)
儲存: microSD
USB: USB 2.0 x 4
Ethernet: 10/100 RJ45
GPIO: 40-pin 2.54 mm (100 mil) expansion header: 2×20 strip
工作電流: 700 mA
尺寸: 85mm x 56mm x 17mm
重量: 42g

《新聞》
- [新聞] Raspberry Pi 2 – Model B 釋出

《下載》
- BCM2836 ARM-local peripherals
- Cortex-A7 MPcore Processor Reference Manual

《相關》
- [產品] Raspberry Pi Model B+ 512MB
- [產品] Raspberry Pi Model A+ 256MB RAM
- [產品] UK製Raspberry Pi Rev 2 Model B 512MB
- 周邊(外殼/電源/SD卡/無線網卡/轉接頭)

$ 1680

Tagged in: 1GBCortex-A7model bQuad-coreraspberry piraspberry pi 2Raspberry Pi 2 Model B Read more...

[產品] Raspberry Pi Model A+ 256MB RAM

2014-11-29 01:09:24 service

raspberry-pi-model-a-plus

規格與 Model A 相同,不同處如下:
* 5V 電源供應增加了一個 2A 的保險絲,因此新版可熱插拔 USB。
* 40 個 GPIO 腳位(原為 26 個腳位)。
* Composite (NTSC/PAL) 視訊輸出和 3.5mm 耳機插孔整合在一起。
* 使用 microSD 卡做為儲存設備(原為 SD 卡)。
* 電路板邊緣做導角設計。
* 將多個接頭移到同一側。
* 更省電(原工作電流為 300mA)。

《規格》

SoC: Broadcom BCM2835
CPU: 700 MHz;ARM1176JZF-S core
GPU: Broadcom VideoCore IV; OpenGL ES 2.0; MPEG-2 and VC-1; 1080p30 h.264/MPEG-4 AVC
記憶體: 256MB SDRAM(和 GPU 共享)
視訊輸出: 3.5 mm jack; HDMI(1.3/1.4)
音訊輸出: 3.5 mm jack; HDMI
儲存: microSD
其他周邊: USB 2.0 x 1; 無Ethernet RJ45
低階週邊: GPIO x17; UART; I²C; SPI; I²S audio; +3.3 V; +5 V; ground
工作電流: 200 mA
尺寸: 65mm x 56mm
重量: 23g

《新聞》
- [新聞] Raspberry Pi Model A+ 釋出

《相關》
- [產品] Adafruit Pi Protector for Raspberry Pi Model A+
- 周邊(外殼/電源/SD卡/無線網卡/轉接頭)

$ 950

Tagged in: 256mbmodel a plusproductraspberry pi Read more...

[產品] Raspberry Pi Model B+ 512MB

2014-08-03 15:35:17 service

Pi-Model-B-Plus-512MB

規格與 Model B 相同,不同處如下:
* 5V 電源供應增加了一個 2A 的保險絲,因此新版可熱插拔 USB。
* 新的 USB/Ethernet 控制晶片。
* 4 個 USB 埠(原為 2 個埠)。。
* 40 個 GPIO 腳位(原為 26 個腳位)。
* Composite (NTSC/PAL) 視訊輸出和 3.5mm 耳機插孔整合在一起。
* 使用 microSD 卡做為儲存設備(原為 SD 卡)。
* 電路板邊緣做導角設計。
* 將多個接頭移到同一側。

更多資訊請看 新聞

技術文件下載
* Connector Schematic
* Mechanical Schematic
* Raspberry Pi Model B+ specs

$ 1600

Tagged in: 512mbModel B Plusproductraspberry pi Read more...

[產品] Wolfson Audio Card for Raspberry Pi Model B

2014-06-27 14:45:02 service

wolfson_audio_card_for_raspberry_pi_512mb

《特色》
* 採用 WM5102 audio hub、WM8804 S/PDIF transceiver 和 WM7220 digital microphone 晶片。
* 內建 1.4W 喇叭擴大機(需外接電源)。
* 可輸出高畫質音效(24-bit/192kHz)。

《規格》
Inputs:
* 3.5mm jack(4-pole) for a headset/boom mic for gaming or VoIP applications
* 2x On-board MEMS microphone
* 3.5 mm jack stereo line input for connection to devices such as digital audio players (iPod etc.) or mobile phones SPDIF Coaxial digital

Outputs:
* 3.5mm jack(4-pole) for a headset/boom mic for gaming or VoIP applications
* 3.5 mm jack for stereo line output for connection to devices such as external stereo amplifiers or powered speakers SPDIF Coaxial digital

Dimensions:
* without jacks: 64mm x 56mm x 1mm
* Weight: 23.8g
* 注意:本音效不包含 Raspberry Pi
* 注意:本音效卡只適用於 Raspberry Pi Model B 512MB

wolfson-audio-card-interface圖片來源:liliputing.com

《新聞》
* [新聞] Wolfson Audio Card:Raspberry Pi專用音效卡

《文件》
* Wolfson Audio Card Schematic Diagram
* User Manual for Wolfson Audio Card
* Wolfson Audio Card

《教學》
* [進階] 安裝 Raspberry Pi 的 Toolchain
* [進階] 編譯 Raspberry Pi 的核心
* Building the Wolfson Audio drivers into the kernel on the Raspberry Pi(編譯 wolfson audio card kernel driver 到 kernel 3.10)
* RPi Linux driver for Wolfson / Cirrus Logic Audio Card(編譯 wolfson audio card kernel driver 到 kernel 4.4.6)

《下載》
* Wolfson Kernel Drivers for Pi(只有 kernel driver source,52KB)
* Pre-build image for Pi(完整 Raspbian 映像檔含 driver,1.7GB)

《相關》
* Raspberry Pi Rev 2 Model B 512MB

$ 1,260

Tagged in: audio cardWM5102WM7220WM8804Wolfsonwolfson audio cardwolfson_audio_card_with_pi_512mb_thumb Read more...

[產品] UK製Raspberry Pi Rev 2 Model B 512MB

2014-04-10 13:39:44 service

Pi-Rev2-Model-B-512MB

《規格》

SoC: Broadcom BCM2835
CPU: 700 MHz;ARM1176JZF-S core
GPU: Broadcom VideoCore IV; OpenGL ES 2.0; MPEG-2 and VC-1; 1080p30 h.264/MPEG-4 AVC
記憶體: 512MB SDRAM(和 GPU 共享)
視訊輸出: Composite RCA; HDMI
音訊輸出: 3.5 mm jack; HDMI
儲存: SD / MMC / SDIO card slot
其他周邊: USB 2.0 x 2; Ethernet RJ45
低階週邊: GPIO x8; UART; I²C; SPI; I²S audio; +3.3 V; +5 V; ground
工作電流: 700 mA
尺寸: 85.60 mm × 56 mm
重量: 45g

$ 1600

Tagged in: 512mbmodel bproductraspberry piPi-Rev2-Model-B-512MB-thumb Read more...

[產品] UK製Raspberry Pi Rev 2 Model A 256MB

2014-04-02 13:15:32 service

Pi-Rev2-Model-A-256MB

《規格》

SoC: Broadcom BCM2835
CPU: 700 MHz;ARM1176JZF-S core
GPU: Broadcom VideoCore IV; OpenGL ES 2.0; MPEG-2 and VC-1; 1080p30 h.264/MPEG-4 AVC
記憶體: 256MB SDRAM(和 GPU 共享)
視訊輸出: Composite RCA; HDMI
音訊輸出: 3.5 mm jack; HDMI
儲存: SD / MMC / SDIO card slot
其他周邊: USB 2.0 x 1; 無Ethernet RJ45
低階週邊: GPIO x8; UART; I²C; SPI; I²S audio; +3.3 V; +5 V; ground
工作電流: 300 mA
尺寸: 85.60 mm × 56 mm
重量: 45g

Tagged in: 256mbmodel aproductraspberry pi Read more...

Leave a Reply

Your email address will not be published. Required fields are marked *


2 × four =


*

You may use these HTML tags and attributes: <a href="" title=""> <abbr title=""> <acronym title=""> <b> <blockquote cite=""> <cite> <code> <del datetime=""> <em> <i> <q cite=""> <strike> <strong>
